Technical Data Sheets
The table below lists our most frequently used adhesives and compounds of our brands
-
Vitralit® – UV curable acrylate and epoxy adhesives
-
Elecolit® – Electrically and thermally conductive adhesives
-
Structalit® – Room temperature and heat curing epoxies
-
Cyanolit® – “Instant” curing adhesives
-
Penloc® – Methacrylate adhesives
Further products and custom solutions are available on request.
To download the technical datasheets (TDS) please click on the adhesive name.
For safety data sheets (SDS) please contact us at info@panacol.de or via our contact form.
Our technical data sheets of the adhesives. They can be found in the tables as PDF for download. Just click on the respective adhesive name.
Vitralit®
| Adhesive | Application | Viscosity [mPas] | Base | Curing* | Properties |
|---|---|---|---|---|---|
| Vitralit® 1505 |
optical cement lens bonding cement glass bonding potting material |
250-400 | epoxy | UV |
Very high glass transition temperature excellent chemical resistance low attenuation |
| Vitralit® 1517 |
lens bonding cement glass bonding |
10,000-20,000 | epoxy |
UV secondary heat cure |
low shrinkage very high Tg low heat expansion |
| Vitralit® 1527 |
optical cement lens bonding cement glass bonding potting material |
600-1,250 | epoxy | UV |
Very high tg low attenuation high transmission high chemical resistance nanostructured fillers |
| Vitralit® 1528 |
optical cement lens bonding cement glass bonding potting material |
350-850 | epoxy |
UV secondary heat cure |
low attenuation very high Tg |
| Vitralit® 1600 LV |
attaching components on PCBs conformal coating encapsulation of electronic components chip encapsulation potting material automotive, aerospace smart card |
3,000-5,000 | epoxy |
UV secondary heat cure |
Very high Tg low water absorption low ion content very high chemical resistance |
| Vitralit® 1605 |
encapsulation of electronic components optical cement lens bonding cement glass bonding potting material |
200-400 (LVT, 25°C, Sp. 2/30 rpm) | epoxy |
UV secondary heat cure |
low shrinkage low heat expansion very high tg excellent chemical resistance certified to ISO 10993-5 standards |
| Vitralit® 1650 |
glob top encapsulation conformal coating encapsulation of electronic components chip encapsulation potting material automotive, aerospace smart card |
3,000-5,000 | epoxy | UV |
Electronic grade low ion content suitable for chip protection UL94 HB test passed |
| Vitralit® 1655 |
conformal coating encapsulation of electronic components glass bonding potting material medical technology |
150-300 | epoxy |
UV secondary heat cure |
flexible certified to USP Class VI and ISO 10993-5 standards resistant to all common sterilization methods |
| Vitralit® 1657 |
glob top encapsulation conformal coating encapsulation of electronic components chip encapsulation potting material attaching components on PCBs SMD assembly display sealing |
5,000-15,000 | epoxy | UV |
Low ion content excellent chemical resistance low water absorption suitable for covering open bonded chips |
| Vitralit® 1671 |
glob top encapsulation conformal coating encapsulation of electronic components chip encapsulation potting material attaching components on PCBs SMD assembly display sealing smart card |
9,000-14,000 | epoxy |
UV secondary heat cure |
Stable frame compound high ion purity electronic grade adhesive high temperature conductivity low water absorption UL94 HB test passed |
| Vitralit® 1680 |
glob top encapsulation conformal coating encapsulation of electronic components chip encapsulation potting material smart card |
5,000-8,000 | epoxy | UV |
Very high resistance to heat and humidity electronic grade adhesive low ion content suitable for chip protection |
| Vitralit® 1688 |
glob top encapsulation conformal coating encapsulation of electronic components chip encapsulation potting material smart card |
1,200-2,000 | epoxy | UV |
Excellent flow properties and leveling electronic grade adhesive low ion content suitable for chip protection excellent resistance to heat and humidity |
| Vitralit® 1691 | glob top encapsulation | 20,000-40,000 | epoxy |
UV secondary heat cure |
black color high ion purity electronic grade adhesive high temperature resistance fast surface curing with UV light |
| Vitralit® 1702 |
plastic bonding, medical technology |
10-100 | acrylate | UV |
Transparent capillary flow biocompatible: certified to USP Class VI standards |
| Vitralit® 1703 |
Medical devices Bonding of larger gaps |
4,000-8,000 | acrylate | UV |
Shear thinning Shape retaining Certified according to USP Class VI Resistant to sterilization |
| Vitralit® 1720 |
Securing components on PCBs Potting for electronic components Fixing electronic components Lens bonding |
2,700-3,700 | epoxy | UV | High temperature resistance |
| Vitralit® 1722 |
attaching components on PCBs encapsulation of electronic components SMD assembly lens bonding cement glass bonding encapsulation of plastic parts plastic bonding potting material automotive, aerospace |
4,000-6,500 | epoxy | UV |
Very high adhesion to most thermoplastics low shrinkage high temperature resistance |
| Vitralit® 2004 F |
conformal coating encapsulation of electronic components potting material automotive, aerospace |
60-100 | epoxy |
UV secondary heat cure |
fluorescing flexible autoclavable dry surface after curing low ion content sprayable |
| Vitralit® 2007 F |
conformal coating encapsulation of electronic components potting material automotive, aerospace |
200-500 | epoxy |
UV secondary heat cure |
fluorescing flexible autoclavable excellent chemical resistance low ion content |
| Vitralit® 2009 F |
conformal coating encapsulation of electronic components potting material automotive, aerospace |
100-200 | epoxy |
UV secondary heat cure |
fluorescing flexible autoclavable high chemical resistance low ion content |
| Vitralit® 2020 |
glass bonding dome coating potting material |
200-400 | epoxy | UV |
Dry surface after UV-curing scratch-resistant transparent |
| Vitralit® 2025 |
glass bonding dome coating potting material |
200-400 | epoxy | UV |
Dry surface after UV-curing scratch-resistant transparent very high chemical and thermal resistance |
| Vitralit® 2028 |
conformal coating encapsulation of electronic components potting material glass bonding automotive, aerospace |
160-300 | epoxy |
UV secondary heat cure |
Dry surface after UV-curing autoclavable excellent chemical resistance scratch resistant coating |
| Vitralit® 2655 | flip chip underfill | 150-300 | epoxy |
UV secondary heat cure |
flexible capillary flow high ion purity |
| Vitralit® 2667 |
flip chip underfill aerospace |
3,000-5,000 (LVT, 25°C, Sp. 4/30 rpm) | epoxy |
UV secondary heat cure |
Low thermal expansion low ion content No outgassing |
| Vitralit® 3385 | optical cement | 1,000-2,500 | acrylate |
UV VIS |
transparent non-yellowing |
| Vitralit® 4282 mod2 |
SMD assembly potting material automotive, aerospace screw locking |
500-600 | acrylate |
UV secondary anaerobic |
UV curing thread locking fast anaerobic post-curing light green color |
| Vitralit® 4451 MV F |
conformal coating plastic bonding plastic film lamination dome coating |
2,000-3,000 (LVT, 25 °C, Sp. 4/30 rpm) | acrylate | UV, VIS |
soft and elastic dry surface after curing protective coating fast curing fluorescing blue |
| Vitralit® 4641 |
display sealing potting material Form In Place Gasket |
1,000-2,500 | acrylate |
UV VIS |
Fast curing elastic flexible high resilience |
| Vitralit® 4730 |
glass bonding display encapsulation encapsulation of plastic parts plastic bonding plastic film lamination |
70-150 | acrylate |
UV VIS |
Capillary flow flexible and tear-proof adhesive suitable for potting dry surface |
| Vitralit® 4731 |
attaching components on PCBs glass bonding display encapsulation encapsulation of plastic parts plastic bonding plastic film lamination medical technology |
900-1,500 (LVT, 25°C, Sp. 3/30 rpm) | acrylate |
UV VIS |
Dry surface after curing, biocompatible: certified to USP Class VI and ISO 10993-5 standards |
| Vitralit® 4731 VT |
glass bonding display encapsulation plastic bonding plastic film lamination lens bonding cement potting material |
4,000-8,000 | acrylate |
UV VIS |
dry surface after curing flexible and tear-proof excellent adhesion to many plastics |
| Vitralit® 4732 VT |
glass bonding display encapsulation plastic bonding plastic film lamination display sealing lens bonding cement potting material |
7,000-9,000 | acrylate |
UV VIS |
Very high adhesion to many plastics dry surface after curing flexible and tear-proof |
| Vitralit® 4735 HC |
attaching components on PCBs glass bonding display encapsulation encapsulation of plastic parts plastic bonding plastic film lamination medical technology |
700-1,000 | acrylate |
UV VIS secondary heat cure |
Very high adhesion to many plastics dry surface after curing flexible and tear-proof suitable for potting |
| Vitralit® 50004 | display bonding | 50-200 | acrylate |
UV VIS |
low shrinkage fast curing optically clear |
| Vitralit® 5140 |
encapsulation of electronic components encapsulation of plastic parts plastic bonding plastic film lamination medical technology potting material |
250-500 | acrylate |
UV VIS |
Flexible, well suited for bonding plastics with low UV translucence and permeable to visible light, biocompatible: certified to USP Class VI standards |
| Vitralit® 5140 VT |
encapsulation of electronic components display sealing plastic bonding plastic film lamination medical technology potting material |
5,000-10,000 (Rheometer, 25°C, 10s^-1) | acrylate |
UV VIS |
High resistance to thermal stress and moisture flexible and stable |
| Vitralit® 6008 VLV | glass bonding | 40-90 | acrylate |
UV VIS |
Capillary flow transparent tack-free surface |
| Vitralit® 6103 |
encapsulation of electronic components SMD assembly potting material automotive, aerospace |
3,500-5,000 | acrylate |
UV secondary heat cure |
Very high adhesion to metals and sintered materials transparent |
| Vitralit® 6104 |
encapsulation of electronic components SMD assembly automotive, aerospace |
3,000-8,000 | acrylate |
UV secondary heat cure |
Very high adhesion to metals and sintered materials |
| Vitralit® 6104 VT |
encapsulation of electronic components SMD assembly attaching components on PCBs automotive, aerospace |
80,000-90,000 (LVT, 25°C, Sp. 4/6 rpm); 8,000-17,000 (Rheometer, 25°C, 10s^-1) | acrylate |
UV secondary heat cure |
Very high adhesion to metals and sintered materials ideal for bonding large components on circuit boards (corner bonding) |
| Vitralit® 6105 |
encapsulation of electronic components SMD assembly automotive, aerospace |
3,500-6,000 | acrylate |
UV secondary heat cure |
very high adhesion to metals and sintered materials |
| Vitralit® 6108 |
glass bonding medical technology potting material |
600-900 | acrylate |
UV VIS secondary heat cure |
non-yellowing excellent flow properties certified to USP Class VI and ISO 10933-5 standards |
| Vitralit® 6108 T |
glass bonding medical technology potting material |
3,000-6,000 | acrylate |
UV VIS secondary heat cure |
non-yellowing excellent gap-filling certified to USP Class VI standards shear thinning |
| Vitralit® 6125 |
attaching components on PCBs potting material encapsulation of electronic components SMD assembly lens bonding cement glass bonding automotive, aerospace |
4,000-6,000 (LVT 25°C, Sp. 4/30 rpm) | acrylate |
UV secondary heat cure |
excellent adhesion to stone, glass, metals and thermoplastics medium viscosity |
| Vitralit® 6127 | glass bonding | 20-100 (LVT 25°C, Sp. 2/60 rpm) | acrylate |
UV secondary heat cure |
high purity specially formulated for bonding glass |
| Vitralit® 6128 |
attaching components on PCBs encapsulation of electronic components SMD assembly lens bonding cement glass bonding potting material |
800-1,200 | acrylate |
UV secondary heat cure |
very high adhesion to stone, glass, metals and thermoplastics high temperature resistance |
| Vitralit® 6128 VT |
attaching components on PCBs encapsulation of electronic components SMD assembly lens bonding cement glass bonding potting material |
18,000-30,000 (LVT, 25°C, Sp. 4/6 rpm); 3,000-6,000 (Rheometer, 25°C, 10s^-1) | acrylate |
UV secondary heat cure |
contains chemical activator high temperature resistance high viscosity excellent adhesion to stone glass metals and thermoplastics |
| Vitralit® 6129 | various application for electronics and PCB assembly | 4,000-7,000 | acrylate |
UV secondary heat cure |
white color very high resistance to heat and chemicals very good thermal conductivity |
| Vitralit® 6133 |
lens bonding cement glass bonding |
600-1,000 (LVT 25°C, Sp. 3/30 rpm) | acrylate |
UV VIS |
High strength and impact resistance very high adhesion to glass metals and anodized aluminium transparent |
| Vitralit® 6134 |
lens bonding cement glass bonding |
700-1,000 | acrylate |
UV VIS |
Very high adhesion to stainless steel stone granite high purity suitable for bonding optical components transparent |
| Vitralit® 6300 |
glass bonding plastic bonding |
2,500-4,000 | acrylate |
UV VIS secondary heat cure |
jetable non-yellowing very high adhesion to glass and metals dual cure |
| Vitralit® 7041 |
Medical technology Needle bonding |
50-90 (LVT 25°C, Sp. 2/60 rpm) | acrylate |
UV VIS |
Excellent adhesion to glass, plastics and metals; biocompatible: certified to USP Class VI standards |
| Vitralit® 7041 F |
Medical technology Needle bonding |
50-90 | acrylate |
UV VIS |
Fluorescing, excellent adhesion to glass, plastics and metals; biocompatible: certified to USP Class VI and ISO 10993/-4/-5 standards |
| Vitralit® 7041 T | Medical technology | 1,500-2,300 | acrylate |
UV VIS |
High viscosity/stable, excellent adhesion to glass, plastics and metals; biocompatible: certified to USP Class VI and ISO 10993/-4/-5 standards |
| Vitralit® 7044 VLV | medical technology | 10-100 | acrylate |
UV VIS |
High peel strength perfect solution for bonding large surfaces flexible |
| Vitralit® 7090 VHS |
Medical technology, plastic bonding |
40-100 | acrylate |
UV VIS |
Dry surface, very high adhesion to plastics, biocompatible: certified to USP Class VI standards |
| Vitralit® 7256 | glass bonding | 600-1,000 | acrylate |
UV |
Non-yellowing transparent |
| Vitralit® 7283 |
medical technology encapsulation of plastic parts plastic bonding |
70-130 | acrylate |
UV VIS |
Perfect solution for bonding large surfaces very high adhesion to glass metals and plastics resistant against all common sterilization methods |
| Vitralit® 7311 |
medical technology encapsulation of plastic parts plastic bonding |
30-100 | acrylate |
UV VIS |
High resistance to alcohols and moisture non-yellowing very high adhesion to plastics, glass and metals suitable for bonding large areas certified according to USP Class VI |
| Vitralit® 7311 T |
medical technology encapsulation of plastic parts plastic bonding |
1,000-3,000 | acrylate |
UV VIS |
High resistance to alcohols and moisture non-yellowing very high adhesion to plastics glass and metals |
| Vitralit® 7313 |
medical technology encapsulation of plastic parts plastic bonding |
40-70 | acrylate |
UV VIS |
Flexible high elongation at break perfect solution for bonding large surfaces very high adhesion to plastics glass and metals |
| Vitralit® 7561 | glass bonding | 500-900 | acrylate |
UV VIS |
Elastic low water absorption perfect solution for bonding large surfaces high resistance to moisture |
| Vitralit® 7562 |
glass bonding medical technology |
500-900 | acrylate |
UV VIS |
Optically clear flexible elastic high resistance to moisture |
| Vitralit® 7631 |
plastic bonding glass bonding potting material |
100-300 | acrylate |
UV VIS |
Very high shear strength and bond strength excellent adhesion to plastics capillary flow behavior |
| Vitralit® 7641 |
plastic bonding glass bonding potting material |
10-100 | acrylate |
UV VIS |
Specially formulated for bonding PMMA high adhesion capillary flow |
| Vitralit® 7642 |
plastic bonding glass bonding potting material |
1,500-2,500 | acrylate |
UV VIS |
Excellent adhesion to many plastics high bond strength excellent flow properties |
| Vitralit® 7989 |
Medical , plastic bonding |
3,000-5,000 | acrylate | UV |
Excellent adhesion to plastics, especially to PC and PMMA; biocompatible: certified to USP Class VI standards |
| Vitralit® 9140 VL |
glass bonding plastic bonding potting material |
1,000-2,000 | acrylate |
UV VIS |
Flexible high resistance to moisture cures thick layers of adhesive |
| Vitralit® 9179 |
encapsulation of electronic components encapsulation of plastic parts potting material SMD assembly |
200-400 | acrylate | UV |
Fast curing very well suited for automated production lines yellow color dry surface |
| Vitralit® 9180 |
encapsulation of electronic components encapsulation of plastic parts potting material SMD assembly |
700-1,200 | acrylate | UV |
Dry surface fast curing of thick layers yellow color |
| Vitralit® 9181 |
encapsulation of electronic components encapsulation of plastic parts potting material SMD assembly |
4,000-7,000 | acrylate | UV |
Yellow color dry surface fast curing of thick layers |
| Vitralit® FIPG 60102 |
potting material display sealing |
100,000-250,000 (Rheometer, 25°C, 10s^-1); 15,000-40,000 (Rheometer, 25°C, 1s^-1) | acrylate |
UV VIS |
Flexible/elastic liquid gasket, high resilience, easy to apply, fast curing with UV light |
| Vitralit® BL UC 1101 |
medical devices optics electronics lens bonding light shielding |
3,500-7,000 (Rheometer, 25 °C, 10s^-1) | epoxy | UV |
black colour low shrinkage low CTE high glass transition temperature good chemical resistance resistant to sterilization |
| Vitralit® BL UC 1102 |
medical devices optics electronics lens bonding light shielding |
3,500-7,000 (Rheometer, 25 °C, 10s^-1) | epoxy | UV |
black colour low shrinkage low CTE high glass transition temperature good chemical resistance resistant to sterilization |
| Vitralit® BL UC 1103 |
medical devices optics electronics lens bonding light shielding |
3,500-7,000 (Rheometer, 25 °C, 10s^-1) | epoxy | UV |
black colour low shrinkage low CTE high glass transition temperature good chemical resistance resistant to sterilization |
| Vitralit® MASK 20100 | UV mask for metal finishing | 200-400 | acrylate |
UV VIS |
Moderate adhesion, water soluble mask, dissolves in hot water |
| Vitralit® MASK 20101 |
UV mask for metal finishing wet acid stripping |
10,000-40,000 | acrylate |
UV VIS secondary heat cure |
Hard, very high adhesion, acid resistant |
| Vitralit® MASK 20102-G |
UV mask for metal finishing sandblasting mask wet acid stripping masks for orthopedic devices |
7,000-15,000 | acrylate |
UV VIS |
Green color, high adhesion, durable |
| Vitralit® MASK 20102-G-Gel | UV mask for metal finishing | 50,000-70,000 | acrylate |
High viscosity, green color, thixotropic gel version of Vitralit MASK 20102-G |
|
| Vitralit® MASK 20104 |
UV mask for metal finishing sandblasting mask masks for orthopedic devices |
14,000-17,000 | acrylate |
UV VIS |
Translucent, moderate adhesion |
| Vitralit® MASK 20107 |
UV mask for metal finishing sandblasting mask masks for orthopedic devices |
40,000-60,000 | acrylate |
UV VIS |
Moderate adhesion |
| Vitralit® MASK 20108 |
UV mask for metal finishing wet acid stripping |
7,000-9,000 | acrylate |
UV VIS secondary heat cure |
brushable thixotropic fast curing easy handling |
| Vitralit® MASK 20109 |
UV mask for metal finishing sandblasting mask |
15,000-40,000 | acrylate |
UV VIS |
Low adhesion |
| Vitralit® MASK 20110 | UV mask for metal finishing | 50,000-70,000 | acrylate |
UV VIS |
Very thick, low adhesion |
| Vitralit® MASK 20111 | UV mask for metal finishing | 30,000-50,000 | acrylate |
Mask for protective coatings, wave solder, white color |
|
| Vitralit® MASK 20114 | UV mask for metal finishing | 90-150 | acrylate | Low viscosity cavity fill | |
| Vitralit® MASK 20115 | UV mask for metal finishing | thixotropic | acrylate |
Controlled flow properties, extremely clean burn-off |
|
| Vitralit® MASK 20116 | UV mask for metal finishing | 50,000-70,000 | acrylate | High viscosity cavity fill | |
| Vitralit® MASK 20117 | UV mask for metal finishing | 20,000-30,000 | acrylate |
Very high adhesion, peelable mask, green color |
|
| Vitralit® UC 1406 |
Automotive Fiber-reinforced windings for electrical composite components |
250-450 | epoxy |
UV VIS |
Very good wetting properties Electrically insulating High glass transition temperature Solvent-free Ideal for filament winding |
| Vitralit® UC 1407 |
General bonding Filament winding |
1,500-2,000 (Rheometer, 25°C) | epoxy |
UV |
Impact resistant Good chemical resistance Ideal for filament winding processes |
| Vitralit® UC 1618 |
optical cement lens bonding cement |
500-1,000 | epoxy |
UV secondary heat cure |
high glass transition temperature high chemical resistance transparent low thermal expansion |
| Vitralit® UC 1619 |
optical cement lens bonding cement |
3,000-5,500 | epoxy |
UV secondary heat cure |
low ion content non-yellowing low thermal expansion |
| Vitralit® UC 6025 | plastic bonding | 1,000-3,000 | epoxy |
UV VIS |
flexible, easy to dispense, very high adhesion to plastic |
| Vitralit® UC 6215 |
dome coating potting material |
400-1,100 | epoxy | UV |
Low outgassing high temperature resistance slightly flexible high ion purity suitable for potting |
| Vitralit® UC 6215 T |
dome coating potting material |
2,000-4,500 | epoxy | UV |
jettable impact resistant very high adhesion to glass and metal suitable for creating "drop-effects" on glass or plastic |
| Vitralit® UC 6684 | dome coating | 1,500-2,500 | epoxy | UV |
Transparent brilliant and dry surface scratch resistant |
| Vitralit® UC 6686 | dome coating | 55,000-70,000 | epoxy | UV | suitable for dome coatings and "drop-effects" on glass or plastic, scratch-resistant, non-yellowing |
| Vitralit® UC 6772 | Dome Coating | 200-400 | epoxy | UV | Scratch-resistant, brilliant surface |
| Vitralit® UD 1405 |
Automotive Filament Winding |
250-450 | epoxy |
UV VIS thermal |
Ideal for fiber-reinforced windings for electrical composite components Very good wetting properties Resistant to temperature Electrically insulating Transparent, one-component |
| Vitralit® UD 2018 | attaching components on PCBs | 11,000-25,000 (Rheometer, 25°C, 10s^-1) | epoxy |
UV secondary heat cure |
Resistant to temperature cycles low shrinkage low thermal expansion coefficient red color pink fluorescent |
| Vitralit® UD 4292 F |
bonding electronic components automotive aerospace screw locking bonding ball bearings |
40-70 (LVT 25°C, Sp. 2/30 rpm) | acrylate |
UV VIS secondary anaerobic |
capillary flowing, bluish fluorescent, high Tg, secondary anaerobic curing |
| Vitralit® UD 5134 |
attaching components on PCBs SMD assembly lens bonding cement plastic bonding potting material automotive, aerospace |
15,000-25,000 | acrylate |
UV VIS secondary heat cure |
Acrylate-Hybrid low thermal expansion low shrinkage impact resistant dry surface grey color |
| Vitralit® UD 5180 |
glob top encapsulation attaching components on PCBs conformal coating encapsulation of electronic components SMD assembly plastic bonding potting material automotive, aerospace |
4,000-6,000 | epoxy |
UV secondary heat cure |
Perfect solution for bonding flexible circuit paths resistant to reflow processes grey color |
| Vitralit® UD 8050 | Conformal Coatings | 8,000-11,000 | acrylate |
UV VIS secondary moisture cure |
Isocyanacrylate fast moisture post-curing in shadowed areas easy to dispense with jet or dispenser e.a. resistant to moisture fixing and protecting electronic components |
| Vitralit® UD 8050 LV | Protective Coating | 200-400 (Rheometer, 25°C, 5s^-1) | acrylate |
UV, VIS, moisture postcuring |
Moisture post-curing in shadowed areas; tack-free surface |
| Vitralit® UD 8055 |
Protective encapsulation of electronic components on PCBs Consumer electronics |
5,000-8,000 (Rheometer, 25°C, 10^-1) | acrylate |
UV VIS moisture cure |
High Tg Fast curing Compatible with flux Low ion content |
| Vitralit® UD 8056 |
Consumer Electronics Protective encapsulation of electronic components on PCBs |
3,000-6,000 (Rheometer, 25°C, 10^-1) | acrylate | UV / VIS |
High Tg, fast curing Compatible with flux Low ion content Passed UL94 HB test |
| Vitralit® UD 8540 |
display bonding display lamination |
1,800-3,200 (Rheometer, 25°C, 10s^-1) | acrylate |
UV VIS secondary moisture cure |
optically clear low shrinkage dual curing |
| Vitralit® UV 2113 |
attaching components on PCBs SMD assembly lens bonding cement plastic bonding potting material |
19,000-32,000 (Rheometer, 25°C, 10s^-1) | acrylate |
UV VIS |
Acrylate hybrid superior strength low thermal expansion impact resistant low shrinkage resistant to soldering stress excellent flow properties |
| Vitralit® UV 2114 | Protective Coating | 10,000-15,000 | acrylate |
UV VIS |
Very good adhesion to many substrates; for bonding and sealing of plastics, glass and metal |
| Vitralit® UV 2115 |
lens bonding cement attaching components on PCBs SMD assembly plastic bonding potting material automotive, aerospace |
20,000-30,000 (Rheometer, 25°C, 50s^-1) | acrylate |
UV VIS |
Acrylate hybrid superior strength low thermal expansion low shrinkage impact resistant resistant to soldering stress paste-like stable and high viscous |
| Vitralit® UV 2150 |
encapsulation of plastic parts plastic bonding plastic film lamination potting material |
140-500 | acrylate |
UV VIS |
Modified acrylate impact resistant fast curing very high adhesion to plastics |
| Vitralit® UV 2415 |
glass bonding lens bonding cement potting material |
1,500-2,500 | acrylate |
UV VIS |
High bond strength impact resistant dry surface resistant to high temperatures and chemicals |
| Vitralit® UV 2725 | glass bonding | 200-400 (LVT 25°C, Sp. 2/30 rpm) | acrylate |
UV VIS |
High peel strength flexible optically clear for bonding large surfaces |
| Vitralit® UV 4050 |
medical technology plastic bonding needle bonding medical disposables |
140-500 (LVT, 25°C, Sp. 2/30 rpm) | acrylate |
UV VIS |
Certified to ISO 10993-5 and USP Class VI standards modified acrylate impact resistant very fast curing very high adhesion to plastics |
| Vitralit® UV 7030 | Medical devices | 15,000-25,000 (Rheometer, 25 °C, 10s^-1) | acrylate |
UV VIS |
Flexible, high elongation at break, very high shear strength, certified according to USP Class VI |
| Vitralit® VBB-1 |
encapsulation of electronic components glass bonding display encapsulation plastic film lamination plastic bonding potting material |
1,000-1,500 | acrylate |
UV VIS |
Elastic high peel strength optically clear very flexible suitable for potting |
| Vitralit® VBB 1 Gel |
attaching components on PCBs SMD assembly glass bonding display sealing display encapsulation plastic bonding potting material |
12,000-30,000 | acrylate |
UV VIS |
Elastic high peel strength optically clear very flexible stable gel |
| Vitralit® VBB-2N LV |
bonding rubber and latex display encapsulation plastic film lamination glass bonding |
10-100 | acrylate |
UV VIS |
Flexible perfect solution for bonding large surfaces high peel strength |
| Vitralit® VBB-N |
display encapsulation plastic film lamination glass bonding |
50-150 | acrylate |
UV VIS |
Transparent elastic high peel strength |
| Vitralit® VBB-N2 SV |
display encapsulation plastic film lamination glass bonding |
300-500 | acrylate |
UV VIS |
very elastic high peel strength suitable for large-area bonding |
| Vitralit® VBB-P | bonding of luxury packaging | 30,000-35,000 | acrylate |
UV VIS |
Excellent adhesion to plastics, especially ionomer resins such as Surlyn non-yellowing available in different viscosities |
*UV = 320 - 390 nm VIS = 405 nm
Elecolit®
| Adhesive | Application | Viscosity [mPas] | Base | Curing* | Properties |
|---|---|---|---|---|---|
| Elecolit® 3012 |
bonding electroconductive parts screen printing |
paste-like | epoxy | thermal |
electrically conductive (ICA) thermally conductive suitable for screen printing |
| Elecolit® 3025 |
bonding heat-sensitive components OPV photovoltaics |
80,000-90,000 Mix, 25,000-35,000 part A, 60,000-70 000, part B, (Rheometer, 25 °C, 10s^-1) | 2 component epoxy |
thermal room temperature |
electrically conductive (ICA) thermally conductive |
| Elecolit® 3036 |
bonding heat-sensitive components, bonding flexible circuits |
paste-like | 2 component epoxy |
thermal room temperature |
electrically conductive (ICA) thermally conductive |
| Elecolit® 3043 |
antenna print bonding ceramic fuses |
1,500-3,500 | epoxy | thermal |
electrically conductive (ICA) thermally conductive |
| Elecolit® 3063 |
LCD bonding bonding flexible conductors |
12,000-30,000 (Rheometer, 25 °C, 10s^-1); 150,000-190,000 (LVT. 25 °C, Sp.7/5 rpm) | acrylate |
UV + pressure VIS + pressure |
electrically conductive (ACA) |
| Elecolit® 3064 |
LCD bonding bonding flexible conductors |
150,000-190,000 (LVT, 25 °C, Sp. 7/5 rpm); 12,000-30,000 (Rheometer, 25 °C, 10s^-1) | acrylate |
UV + pressure VIS + pressure |
electrically conductive (ACA) |
| Elecolit® 3065 |
bonding flexible circuits display and touchscreen sealing |
25,000-45,000 (Rheometer 10s^-1) | acrylate |
UV + pressure VIS + pressure thermal postcuring |
Electrically conductive (ACA) Transparent brownish color High flexibility Very high adhesion to PET, Kapton and Mylar |
| Elecolit® 323 | bonding electronic components | paste-like | 2 component epoxy | thermal |
electrically conductive (ICA) thermally conductive ISO 10993-5/-12 certified |
| Elecolit® 325 | bonding heat-sensitive components | paste-like | 2 component epoxy | thermal |
electrically conductive (ICA) thermally conductive |
| Elecolit® 327 | bonding electroconductive parts | paste-like | polyimid | thermal |
electrically conductive (ICA) thermally conductive high temperature resistant up to 275°C |
| Elecolit® 336 | bonding heat-sensitive components | paste-like | 2 component epoxy | thermal, room temperature |
electrically conductive (ICA) thermally conductive |
| Elecolit® 342 | ESD protection | 1,000-2,000 | acrylate | thermal |
electrically conductive (ICA) thermally conductive |
| Elecolit® 3647 |
Die attach Flexible printed circuits Contacting on Flex PCBs Conductive bonding OPV photovoltaics |
7,000 – 12,000 (Rheometer 10s^-1) | epoxy | thermal |
Very flexible, solvent-free Electrically conductive Thermally conductive Very high adhesion to glass, various metals and plastics |
| Elecolit® 3653 |
bonding electroconductive parts ideal for parts subjected to high vibrations |
4,000-8,000 | epoxy | thermal |
electrically conductive (ICA) thermally conductive |
| Elecolit® 3655 | LED die attach | 5,000-15,000 (Rheometer 10s^-1) | epoxy | thermal |
electrically conductive (ICA) thermally conductive, thixotropic, silver color, low ion content (Na+, K+, Cl- <10ppm) |
| Elecolit® 3656 |
die attach semiconductor LED applications |
50,000-70,000 | epoxy | thermal |
silver-containing small grain size high filling density low ion content |
| Elecolit® 3661 | bonding flexible interconnect devices | 20,000-40,000 | epoxy | thermal |
electrically conductive (ICA) thermally conductive stable flexible |
| Elecolit® 414 | printing circuit paths on flexible substrates | 6,000-15,000 | polyester | thermal |
electrically conductive (ICA) thermally conductive |
| Elecolit® 6207 |
encapsulation general potting |
9,000-12,000 | 2 component epoxy |
thermal room temperature |
thermally conductive black color Ul listing |
| Elecolit® 6601 |
Heat sink bonding Sensor bonding Potting |
12,000-20,000 (LVT, 25 °C, Sp. 4/6 rpm) | epoxy | thermal |
thermally conductive, solvent-free, white color, excellent bonding to metals, very good flow properties |
| Elecolit® 6603 |
Magnet bonding Heat sink bonding Potting Thermal management |
95 000 - 115 000 (LVT, 25 °C, Sp. 4/3 rpm) | epoxy | thermal |
thermally conductive grey color very good adhesion to metal excellent flow properties |
| Elecolit® 6604 |
Sensor bonding Heat sink bonding Thermal Management |
110 000 - 140 000 (LVT, 25 °C, Sp. 4/3 rpm); 55 000 - 75 000 (Rheometer 25°C, 10s^-1) | epoxy | thermal |
thermally conductive, very good flow properties grey color |
| Elecolit® 6616 | heat sink bonding | 50,000-120,000 (Rheometer, 25 °C, 10s^-1) | 2 component epoxy |
thermal room temperature |
thermally conductive black color |
*UV = 320 - 390 nm VIS = 405 nm
Structalit®
| Adhesive | Application | Viscosity [mPas] | Base | Curing | Properties |
|---|---|---|---|---|---|
| Structalit® 1028 R | general applications | 16,000-24,000 | 2-part-epoxy | room temperature |
Versatile applications easily dispensable with double cartridge |
| Structalit® 3060 |
attaching components on PCBs SMD assembly die attach smart card plastic bonding |
4,000-7,000 | epoxy | thermal |
Fast curing fixing components on PCBs corner bonding glob top SMD applications |
| Structalit® 3060 N |
structural bonding die attach OPV photovoltaics |
4,000-8,000 (Rheometer, 25 °C, 10^s-1) | epoxy | thermal |
non-conductive high flexibility very fast curing very low ion content |
| Structalit® 5511 |
Wire protection Potting and sealing of temperature sensitive substrates |
800-1,200 | epoxy | thermal at 60°C |
Non-conductive Outstanding adhesion to high performance plastics (LCP, PBT) High purity Electronic grade standard |
| Structalit® 5521 |
Wire protection Potting and sealing of temperature sensitive substrates |
1,200-2,000 (Rheometer, 25°C, 10s^-1) | epoxy | thermal at 60°C |
Non-conductive Outstanding adhesion to high performance plastics (LCP, PBT) High purity Electronic grade standard Flexible |
| Structalit® 5531 |
Wire protection Potting and sealing of temperature sensitive substrates |
5,000-10,000 (Rheometer, 25°C, 10s^-1) | epoxy | thermal at 60°C |
Non-conductive Outstanding adhesion to high performance plastics (LCP, PBT) High purity Electronic grade standard Good mechanical stability Good chemical resistance |
| Structalit® 5604 |
attaching components on PCBs SMD assembly die attach smart card plastic bonding |
25,000-40,000 (Rheometer, 25 °C, 10s^-1) | epoxy | thermal |
Fast curing red color fixing components on PCBs SMD applications |
| Structalit® 5610 |
attaching components on PCBs SMD assembly |
22,000-40,000 | epoxy | thermal |
very fast curing even at low temperatures high temperature resistance red color |
| Structalit® 5704 |
Frame-material for Frame&Fill Glob top Electrics Electronics |
60,000-100,000 | epoxy | thermal |
black color stable frame suitable in combination with fills Structalit 5717-5721 no bleeding very low ion content (<10ppm) high glass transition temperature |
| Structalit® 5606 F |
PCBs and Electronics Attaching components and SMDs |
22 000 - 30 000 (LVT, Sp. 4/6 rpm) | Epoxy | Thermal |
1part epoxy, fluorescing bluish Fast curing at low temperatures High shock resistance Short time resistant to soldering temperatures up to 270° C |
| Structalit® 5705 |
Edge Bonding, Applications on PCBs |
7,000-12,000 | epoxy |
thermal |
Black color, yellow fluorescent, reworkable above 150°C, jettable, low in halogens, very suitable as edge bonding adhesive |
| Structalit® 5717 |
Fill-material for "Frame&Fill" Glob top Electrics Electronics |
3,000-8,000 (Rheometer, 25°C, 10s^-1) | epoxy | thermal |
Black color, very good flowability High glass transition temperature No bleeding Very low ionic content (<10ppm) Suitable for semiconductors |
| Structalit® 5719 |
Fill-material for "Frame&Fill" Glob top Electrics Electronics |
7,000-11,000 (Rheometer, 25°C, 5s^-1) | epoxy | thermal |
Very good flowability High glass transition temperature No bleeding Very low ionic content (<10ppm) Suitable for semiconductors |
| Structalit® 5720 |
Fill-material for "Frame&Fill" Glob Top Electrics Electronics |
10,000-15,000 (Rheometer, 25°C, 5s^-1) | epoxy | thermal |
Very good flowability High glass transition temperature No bleeding Very low ionic content (<10ppm) suitable for semiconductors |
| Structalit® 5721 |
Fill-material for "Frame&Fill" Glob top Electrics Electronics |
15,000-20,000 | epoxy | thermal |
Very good flowability High glass transition temperature No bleeding Very low ionic content (<10ppm) Suitable for semiconductors |
| Structalit® 5751 | Underfill | 200-500 (Rheometer, 25°C, 10s^-1) | epoxy | thermal | Black color, fluorescent yellow, jetable, low ion content, reworkable above 150°C |
| Structalit® 5791 |
Frame-material for "Frame&Fill" Glob top Electrics Electronics |
45,000-65,000 | epoxy | thermal |
black color excellent shock resistance low halogen content <900 ppm |
| Structalit® 5800 |
encapsulation of electronic components potting material encapsulation of plastic parts plastic bonding automotive, aerospace |
12,000-22,000 part A (LVT 25°C, Sp. 4/12 rpm); 500-800 part B (LVT 25°C, Sp. 2/30 rpm); 7,000-15,000 mix (LVT, 25°C, Sp. 4/30 rpm) | 2-part epoxy | thermal, room temperature |
High temperature resistance short pot life fast application |
| Structalit® 5801 |
encapsulation of electronic components potting material encapsulation of plastic parts |
12,000-22,000 mix, 10,000-20,000 part A, 18,000-29,000 part B, (Rheometer, 25 °C, 10s^-1) | 2-part epoxy | thermal, room temperature |
Black color Excellent oil, chemical and moisture resistance Low shrinkage Low water absorption Good adhesion to metal, glass and plastics |
| Structalit® 5802 |
encapsulation of electronic components potting material encapsulation of plastic parts plastic bonding automotive, aerospace |
25,000-35,000 part A; 80,000-100,000 part B; 40,000-65,000 mix (Rheometer, 25°C, 10s^-1) | 2-part epoxy | thermal, room temperature |
Excellent oil, chemical and moisture resistance Low shrinkage Low water absorption Good adhesion to metal, glass and plastics Dark grey color |
| Structalit® 5810-1 |
encapsulation of electronic components and plastic parts potting material plastic and glass bonding automotive, aerospace |
1,000-1,500 part A (LVT 25°C, Sp. 3/30 rpm); 3,500-4,500 part B (LVT 25°C, Sp. 4/30 rpm); 3,000-4,000 mix (LVT, 25°C, Sp. 4/30 rpm) | 2-part epoxy |
thermal room temperature |
Very high adhesion to PC resistant to moisture and chemicals |
| Structalit® 5811 |
Coating, potting material Bonding of metals, glass and many pastics |
Part A: 900-1,300, Part B: 100-350 | 2-part epoxy | thermal, room temperature | Very good adhesion to metals, glass and many plastics |
| Structalit® 5820 | potting material | 20,000-25,000 | epoxy | thermal |
transparent high adhesion to metals |
| Structalit® 5830 |
SMD assembly potting material automotive, aerospace |
28,000-38,000 (LVT, 25°C, Sp. 4/6 rpm) | epoxy | thermal |
Yellow color adheres well to metal impact resistant high peel strength |
| Structalit® 5891 |
glob top encapsulation plastic bonding SMD assembly |
25,000-50,000 | epoxy | thermal |
Black color fast curing at low temperatures impact resistant |
| Structalit® 5891 T |
glob top encapsulation SMD assembly attaching components on PCBs |
80,000-150,000 | epoxy | thermal |
Black color stable frame material, can be applied wet-in-wet with filling material, suitable for frame stacking stable edges resistant to shocks |
| Structalit® 5893 |
glob top encapsulation SMD assembly medical technology needle bonding frame&fill |
6,000-10,000 (Rheometer, 25°C, 10s^-1) | epoxy | thermal |
Black color excellent flow properties filling material for frame&fill applications high resistance to heat and chemicals certified to ISO 10993-5 standards |
| Structalit® 5894 M |
glob top encapsulation encapsulation of electronic components SMD assembly automotive, aerospace potting material |
20,000-30,000 (Rheometer, 25 °C, 20s ^-1) | epoxy | thermal |
Black color excellent flow properties filling material for frame and fill applications on PCBs, very high resistance to heat and chemicals |
| Structalit® 701 |
lens bonding cement optical cement medical technology |
3,000-5,000 | 2-part epoxy | thermal |
Transparent in thin layers long potlife fast curing certified to USP Class VI and ISO 10993-5 standards |
| Structalit® 8202 |
Electronics Automotive Underfill for chip stack packages Protection of soldered connections |
300-400 (Rheometer, 25°C, 10s^-1) | epoxy | thermal |
Black, fast curing Capillary flow behavior Compatible with flux materials Low CTE, high glass transition temperature Low ion content (Cl- <900ppm) |
| Structalit® 8801 |
attaching components on PCBs encapsulation of electronic components SMD assembly encapsulation of plastic parts potting material automotive, aerospace |
30,000-45,000 (LVT, 25°C, Sp. 4/6 rpm) | epoxy | thermal |
Resistant to oils, grease and fuels excellent flow properties beige color certified to ISO 10993-5 standards |
| Structalit® 8801 black |
attaching components on PCBs encapsulation of electronic components SMD assembly encapsulation of plastic parts potting material automotive, aerospace |
30,000-45,000 | epoxy | thermal |
Resistant to oils, grease and fuels black color excellent flow properties |
| Structalit® 8801 T |
attaching components on PCBs encapsulation of electronic components SMD assembly encapsulation of plastic parts potting material automotive, aerospace |
16,000-30,000 | epoxy | thermal |
Resistant to oils, grease and fuels stable |
| Structalit® 8805 |
attaching components on PCBs encapsulation of electronic components SMD assembly encapsulation of plastic parts potting material automotive, aerospace |
30,000-45,000 | epoxy | thermal |
Resistant to oils, grease and fuels excellent flow properties beige color |
| Structalit® 8838 |
attaching components on PCBs encapsulation of electronic components SMD assembly |
6,500-7,500 (Rheometer, 25°C, 20s^-1) | epoxy | thermal |
Black color flexible potting compound excellent flow properties |
| Structalit® 8926 |
attaching components on PCBs encapsulation of electronic components SMD assembly encapsulation of plastic parts potting material automotive, aerospace |
30,000-45,000 | epoxy | thermal |
Resistant to oils grease and fuels excellent flow properties beige color |
Cyanolit®
| Adhesive | Application | Viscosity [mPas] | Base | Curing | Properties |
|---|---|---|---|---|---|
| Cyanolit® 200 | plastic bonding | 1-3 | cyanoacrylate |
moisture, room temperature |
Capillary flow |
| Cyanolit® 201 | plastic bonding | 1-3 | cyanoacrylate |
moisture, room temperature |
Capillary flow |
| Cyanolit® 202 | plastic bonding | 70-100 | cyanoacrylate |
moisture, room temperature |
Capillary flow |
| Cyanolit® 203 TX |
Plastic bonding, medical technology |
shear thinning | cyanoacrylate |
moisture, room temperature |
Biocompatible: certified to USP Class VI standards |
| Cyanolit® 241 F |
Plastic bonding, bonding of luxury packaging, medical technology |
30-50 | cyanoacrylate |
moisture, room temperature |
Capillary flow, biocompatible: certified to USP Class VI standards |
| Cyanolit® 401 X | metal bonding | 1-3 | cyanoacrylate |
moisture, room temperature |
Capillary flow |
| Cyanolit® 732 F |
Plastic bonding, medical technology, smart card |
230-350 (LVT, 25 °C, Sp. 2/60 rpm) | cyanoacrylate |
moisture, room temperature |
Film forming, suitable for bonding porous materials, biocompatible: certified to USP Class VI standards |
| Cyanolit® 811 F | plastic bonding | 4-12 (LVT, 25 °C, Sp. 2/60 rpm) | cyanoacrylate |
moisture, room temperature |
odorless |
| Cyanolit® Gel 10 | plastic bonding | 100,000-240,000 | cyanoacrylate |
moisture, room temperature |
Shear thinning gel-like |
Penloc®
| Adhesive | Application | Viscosity [mPas] | Base | Curing | Properties |
|---|---|---|---|---|---|
| Penloc® GTH-T |
plastic bonding potting material automotive, aerospace metal bonding joining hinges |
8,000-10,000 part A, part B, mix (LVT, 25 °C, Sp.4 / 30 rpm) | 2-part-acrylate | room temperature |
Very high adhesion to metal temperature resistant |
| Penloc® GTI |
plastic bonding potting material automotive, aerospace joining hinges |
4,000-6,000 part A, part B (LVT, 25 °C), 5,000 mix (LVT, 25 °C, Sp.4 / 30 rpm) | 2-part-acrylate | room temperature | Fast curing |
| Penloc® GTI-C |
glass bonding potting material |
5,000-6,000 (LVT, 25 °C, Sp. / rpm) mix | 2-part-acrylate | room temperature | Translucent |
| Penloc® GTI-S |
plastic bonding potting material automotive, aerospace |
5,000-6,000 part A, part B, mix (Brookfield LVT, 25 °C) | 2-part-acrylate | room temperature |
Flexible resistant to high temperatures high flash point |
| Penloc® GTN |
Plastic bonding Potting Material Automotive, Aerospace Bonding of luxury packaging Joining hinges |
15,000-30,000 Part A, 20,000-40,000 Part B (LVT, 25°C, Sp. / rpm) | 2-part-acrylate | room temperature |
resistant to high temperatures high flash point flexible low odour |
| Penloc® GTR |
plastic bonding potting material automotive, aerospace |
4,000 (LVT, 25 °C, Sp.4 / 30 rpm) mix | 2-part-methacrylate | room temperature |
Flexible resistant to high temperatures high flash point |
| Penloc® GTR-VT |
plastic bonding potting material automotive, aerospace |
20,000-30,000 (LVT, 25 °C, Sp.4 /30 rpm) mix | 2-part-acrylate | room temperature |
Shape retaining green color overhead application possible |
